Agilent HP-5ms Ultra Inert GC Columns
Main image
Click to view image in fullscreen
![]()
All pictures shown are for illustration purpose only. Actual product may vary.
Agilent J&W HP-5ms Ultra Inert is a (5%-phenyl)-methylpolysiloxane specifically tested for inertness in the analysis of active compounds, including acidic and basic compounds, to meet the growing need for lower detection levels. With very low bleed characteristics, this bonded and crosslinked column is solvent rinsable and ideal for GC/MS. It is equivalent to USP phase G27 and features improved signal-to-noise ratio for better sensitivity and mass spectral integrity.
Features
- Excellent for trace-level analysis of acids and bases
- (5%-Phenyl)-methylpolysiloxane has identical selectivity to HP-5MS
- Specifically tested for inertness for active compounds, including acidic and basic compounds
- Improved signal-to-noise ratio for better sensitivity and mass spectral integrity
- Nonpolar with very low bleed characteristics, ideal for GC/MS
- Bonded, crosslinked, and solvent rinsable
- Equivalent to USP phase G27
- Tested with the tightest industry QC specifications for column bleed, sensitivity, and efficiency
- Performance Summary shipped with each column
Similar phases: Rtx-5ms, Rxi-5ms, Rxi-5Sil MS, PTE-5, BPX-5, AT-5ms, ZB-5ms, ZB-5ms Plus, SLB-5ms, Equity-7
Specification
HP-5ms Ultra Inert Temperature Specifications
| ID (mm) | 0.18 – 0.32 mm |
| Length (m) | 15 – 60 m |
| Film (µm) | 0.18 – 1.00 µm |
| Temperature Limits (°C) | -60 – 325/350 °C |
Literature
Full range of Agilent Technologies GC columns and applications
Detect every peak and minimize degradative buildup in your GC flow path
Optimising your GC flow path for inertness
For best trace level analysis, maintain your inert flow path with Agilent inert flow path components
